Populating Dependent Picklist Values in Omniscript Inputs with Apex

You can populate Select, Multi-select, and Radio elements from a Callable implementation. The values for the element are obtained during the Omniscript's activation.

When populating a Dependent Picklist through Apex, the returned Picklist Options are a Map<String, List<Map<String, String>>. The keys to the initial Map are the Language Independent ('name') options from the Controlling field. The List<Map> Options are 'Name' the Language Independent Option and 'Value' the UI Display value. For information on populating a picklist with no dependencies, see Populating Picklist Values in Omniscript Inputs from Apex.

The order of values from the Omniscript is the order of the output picklist.

Sample Apex Code:

global class PicklistPopulationExample implements Callable {
    public Object call(String action, Map<String, Object> args) {
        Map<String, Object> input = (Map<String, Object>)args.get('input');
        Map<String, Object> output = (Map<String, Object>)args.get('output');
        Map<String, Object> options = (Map<String, Object>)args.get('options');
        return invokeMethod(action, input, output, options);
    }
    public Boolean invokeMethod(String methodName, Map < String, Object > input, Map < String, Object > outMap, Map < String, Object > options) {
        if (methodName.equals('PopulateDependentPicklist')) {
            PopulateDependentPicklist(input, outMap, options);
        }
        else if (methodName.equals('PopulatePicklist')) {
            PopulatePicklist(input, outMap, options);
        }
        return true;
    }

    // add the map under options to populate the picklist
    public void PopulatePicklist(Map<String, Object> input, Map<String, Object> outMap, Map<String, Object> options)
    {
        // hard coded list, these options could be results from a remote call/3rd party api
        List<Map<String,String>> picklist = new List<Map<String, String>>();

        Map<String, String> picklistOption = new Map<String, String>();
        picklistOption.put('name', 'Licensing & Permitting');
        picklistOption.put('value','Licensing & Permitting');
        picklist.add(picklistOption);

        picklistOption = new Map<String, String>();
        picklistOption.put('name', 'Contract');
        picklistOption.put('value','Contract');
        picklist.add(picklistOption);

        outMap.put('options', picklist);
    }

    // add the map of all possible picklists that will be chosen given the "controllingElement"
    // note that the "controllingElement" is an element name that gets passed in from omniscript
    public void PopulateDependentPicklist(Map<String, Object> input, Map<String, Object> outMap, Map<String, Object> options)
    {
        // Map of List where the Key is the Potential Values in the Other Picklist
        Map<String, List<Map<String, String>>> dependency = new Map<String, List<Map<String, String>>>();

        List<String> controlValList = new List<String>();
        // note that these are listed (above)
        controlValList.add('Licensing & Permitting');
        controlValList.add('Contract');

        // generating arbitrary entries for each of the above keys
        for(Integer i=0; i<2; i++)
        {
            List<Map<String, String>> optionList = new List<Map<String, String>>();

            for(Integer j=0; j<2; j++) {
                Map<String, String> tempMap = new Map<String, String>();
                tempMap.put('name', controlValList[i] + ' Child');
                tempMap.put('value', controlValList[i] + ' ChildV');

                optionList.add(tempMap);
            }
            dependency.put(controlValList[i], optionList);
        }

        outMap.put('dependency',dependency);
   }


}
